BW600Y35 High-Precision High-Flow Industrial Peristaltic Pump | 13 L/min Multi-Channel Variable Speed Pump
BW600Y35 High-Precision High-Flow Industrial Peristaltic Pump | 13 L/min Multi-Channel Variable Speed Pump
Couldn't load pickup availability
Online price is for samples. Contact us for bulk discount.
BW600Y35 Peristaltic Pump-Data Sheet
The BW600Y35 Industrial Variable Speed Peristaltic Pump is designed for high-volume liquid transfer and automated fluid handling. Powered by a stepper motor, it provides a speed range of 0.1–600 rpm and a maximum flow rate of 13,000 mL/min (13 L/min).
The pump combines variable speed control, forward/reverse operation, quick full-speed operation, power-off memory, and RS485 Modbus communication, making it suitable for industrial equipment and automated fluid control systems.
Key Features
High-Flow Transfer
The pump delivers up to 13 L/min, depending on the selected tubing and roller configuration, making it suitable for continuous industrial liquid transfer.
Precise Speed Adjustment
A speed range of 0.1–600 rpm with 0.1 rpm resolution allows users to adjust the pumping rate according to application requirements.
RS485 Modbus Communication
The integrated RS485 interface with Modbus protocol allows connection to PLCs, HMIs, computers, and other automation systems.
Forward and Reverse Operation
The motor can run in both directions, providing flexible flow direction control and convenient tubing emptying and cleaning.
Quick Full-Speed Function
The one-touch full-speed function helps accelerate tubing filling, draining, and cleaning procedures.
Power-Off Memory
Operating settings are automatically retained when power is interrupted, simplifying operation after restart.
Multi-Head Expansion
Multiple pump heads can be configured for applications requiring simultaneous transfer through multiple channels.
Technical Specifications
| Specification | Details |
|---|---|
| Model | BW600Y35 |
| Pump Type | Industrial Variable Speed Peristaltic Pump |
| Flow Rate | 7–13,000 mL/min |
| Speed Range | 0.1–600 rpm |
| Speed Resolution | 0.1 rpm |
| Speed Error | ≤0.1% |
| Outlet Pressure | ≤0.55 MPa |
| Standard Power Supply | 220V ±10%, 50/60Hz |
| Optional Power Supply | 110V ±10%, 50/60Hz |
| External Control Interface | Optional |
| Communication Interface | RS485 |
| Communication Protocol | Modbus |
| Operating Temperature | 0–40°C |
| Operating Humidity | <80% RH |
| Protection Rating | IP31 |
| Operating Mode | Continuous Transfer |
Tubing & Flow Reference
| Tubing | ID × Wall × OD | 3 Rollers | 4 Rollers | 5 Rollers |
|---|---|---|---|---|
| 26# | 6.4 × 3.5 × 13.4 mm | 0.72–4300 mL/min | 0.68–4050 mL/min | 0.58–3770 mL/min |
| 73# | 9.7 × 3.5 × 16.7 mm | 1.3–8000 mL/min | 1.3–7800 mL/min | 1.05–6500 mL/min |
| 82# | 12.7 × 3.5 × 19.7 mm | 2.1–13000 mL/min | 2–12000 mL/min | 1.3–8000 mL/min |
Actual flow performance depends on tubing size, roller configuration, pump speed, and fluid characteristics.
Control Options
The BW600Y35 can be integrated into different control systems through:
- Manual Speed Control – Adjust speed with the control knob
- RS485 Control – Digital communication via Modbus
- I/O Control – External equipment control
- Start/Stop Control – Remote operation
- Direction Control – Forward and reverse switching
Applications
The BW600Y35 is suitable for:
- Medical equipment
- Laboratory instruments
- Food processing
- Liquid dispensing
- Textile and dyeing equipment
- Industrial automation
- Instrument integration
- OEM fluid control systems
